- Conductor: Stranded Bare Copper or Solid Bare Copper
- Insulation： PVC with CMR Rating
- Jacket: PVC with CMR Rating
- Rip Cord: Nylon
- Rated Voltage: 300V
- Operating Temperature Range：- 20°C ~75°C
- Certificates: UL & ETL
| Item No. | AWG Size | Conductors No. | Strands No. | Insulation Thickness (Mils) | Jacket Thickness (Mils) | O.D. (Inch) |
| SR1802R-Coil | 18 | 2 | 7 | 8 | 15 | 0.16 |
| SR2202R-Coil | 22 | 2 | 7 | 8 | 15 | 0.12 |
| SR2202R-Coil-SOL | 22 | 2 | 1 | 8 | 15 | 0.12 |
| SR2204R-Coil | 22 | 4 | 7 | 8 | 15 | 0.16 |
| SR2204R-Coil-SOL | 22 | 4 | 7 | 8 | 15 | 0.16 |
