- Conductor: Stranded Bare Copper
- Insulation： PVC
- Jacket: LLDPE
- Screen: PE Tape Waterproof
- Rip Cord: Nylon
- Rated Voltage：300V
- Operating Temperature Range：- 20°C ~75°C
- Certificates: UL & ETL
| Item No. | AWG Size | Conductors No. | Strands No. | Insulation Thickness (mm) | Jacket Thickness (mm) | O.D. (Inch) |
| SR1404DB | 14 | 4 | 19 | 0.36 | 0.7 | 8.2 |
| SR1602DB | 16 | 2 | 19 | 0.33 | 0.7 | 5.5 |
| SR1604DB | 16 | 4 | 19 | 0.33 | 0.7 | 6.8 |
| SR1802DB | 18 | 2 | 7 | 0.26 | 0.7 | 5.2 |
